SmartStation Customize Mini PC
Why SMARTSTATION?
Mini PC
SMART 7110 N95
- A full-featured Micro Computer PC
- Support HDD, Vesa Mounting
- 2x USB3.2 Gen2(Type-A Double Layer),
- 2x HDMI 2.0 (4k@60Hz)
SMART 9530 Mini pc Product Highlight
| Category | Type | Description |
|---|---|---|
| Basic Information | CPU | Onboard Intel Core i3-1215U |
| TDP | 15W | |
| Motherboard | 12 x 12 cm | |
| Chipset | Intel Alder Lake | |
| Memory | 2x SO-DIMM DDR5 Slot Support 8GB/16GB/32GB/64GB | |
| OS | Windows 10/11, WES 10, Linux | |
| PXE | Yes | |
| Audio | Intel High Definition Audio and USB Audio and HID | |
| Network | 2x Onboard RTL8111 Gigabit Ethernet NIC 10/100Mbps/1000Mbps BaseT LAN | |
| Video | Intel UHD Graphics for 12th Gen Intel Processors | |
| Wi-Fi | Module | 1x mini PCIE-full/mini PCIE-half port for WiFi/Bluetooth Module 1x mini PCIE-haf/full port for 3G/4G module |
| Antena | 2 x inner RF cables and 2 x external antennas | |
| Input/output port | Switch | 1x Power On/Off Switch |
| Power | 1x 12V-19V DC In | |
| USB | 4x USB2.0, 4x USB3.0 | |
| Display | 1x HDMI 1.4,1x VGA | |
| LAN | 2x RJ45 Giga LAN | |
| COM | 2x DB9 RS232 COM | |
| Audio | 1x MIC, 1x SPK | |
| Storage | NVME | 1x M.2 slot NVME/NGFF 2280 SSD |
| SATA | 1x SATA3.0 Slot for SATA HDD or SSD, support 6Gb/s | |
| Power and Working Environment: | Input | 100-240V AC/50-60Hz |
| Output | DC+12V~+19V, recommend 12V/5A | |
| Operating Temperature | -20°C/+60°C | |
| Storage Temperature | -30°C/+70°C | |
| Relative Humidity | 10%~90% @30°C(non-condensing) | |
| Production Dimension & Details | Size | 193.9 x1 27x 57.2 mm |
| Weight | Net 1kg, Gross 1.5kg | |
| Shell | Black color aluminum alloy | |
| Mounting | 4 mounting holes on the case baseplate | |
| Cooling Mode | Fanless | |
| Functions | AWAL, Wake On LAN, RTC, Watchdog | |
| Package Content | Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1x Screws Bag |
| Optional | Wi-Fi antennas, 1xHDMI cable, 1x User Manual, 1x long Screws Bag |
