SMART 9550 I5 12th Gen OPS (EURO)

Alder Lake Intel Core i5-1235U Processor, up to 4.40 GHz, 10 Cores, 12 Threads, 12 MB Cache, TDP 15W, Intel® Iris® Xe Graphics

High-performance Mini PC SMART 7130 powered by 12th Gen Core i3 for fast, efficient, and reliable computing.

SMART 9550 I5 12th Gen OPS (EURO)

Smart 9550 i5 12th Gen OPS delivers powerful performance with Intel Core i5 processing, triple display support, and high-speed NVMe storage compatibility. Designed for conference rooms, classrooms, and digital signage applications, it supports 4K output, TPM 2.0, Intel vPro, and seamless integration through an advanced 80-pin JAE connector system.

Download BrochureDownload Brochure

Processor

Alder Lake Intel Core i5-1235U Processor up to 4.40GHz

GPU

Intel UHD Graphics / Intel Iris Xe Graphics
Dual Display ( HDMI + DP )

I/O Interfaces

1x HDMI 2.0 (4k@60Hz) & 1x DP 1.4
2x USB 3.0, 4x USB 2.0
1x Type-C (USB 3.0 + Video)
1x Line out,1x Mic in,
80 PIN JAE Connector

Memory

SO-DIMM DDR4 slot 3200MHz Max 32GB

SMART 9550 I5 12th Gen OPS (EURO)

Multi-OS Compatibility

Windows 10 (or higher) and Linux

Storage

M.2 2280 NVME SSD

High-Speed LAN

1x RJ45 Giga LAN
Wi-Fi 5/ 6 + Bluetooth 5.0 combo

Key Features

Euro Size : 118x 180x 30mm
An 80-pin JAE connector that truly innovative “slot-in” system design
Ideal use for Deployment in Conference Rooms, Classrooms,
Shopping Malls, and other Retail Sites etc.

SMART 9550 I5 12th Gen OPS (EURO) Technical Specification

Category	Type	Description
Parameter	CPU	Intel Core i5-12th Gen 1235U Processor 10 Cores 12 Threads
	RAM	2x SO-DIMM DDR4 2666/3200MHz
	Storage	1x M.2 2280 NVMe SSD Slot
	Graphics	Intel Iris Xe Graphics eligible
	Display Output	HDMI/DP/Type-C Support synchronous dual display
	Internet	LAN : 1 x RJ45 Realtek PCIe GbE Family Controller Wi-Fi : 1x M.2 2230 for WiFi + BT
	Audio	Cmedia USB Audio (HS100B)
I/O Port	Front Port	1x HDMI 2.0 out, 1x DP 1.4 out, 4 x USB 2.0, 2 x USB 3.0, 1x RJ45, 1x Power, 1x Restore, 1x Line out, 1x Mic in, 1x Type-C (USB 3.0 + Video transmission), 1x Power LED, 1x HDD/SSD LED, 2x WiFi/BT ANT
	Rear Port	1x JAE 80PIN : (HDMI 2.0 out 4K/60Hz)
Power Parameters	Power Supply	19V / 4.7A
Size	Size (mm)	Physical Size: 118 x 180 x 30mm
	Weight (Kg)	N.W = 1.2 KG G.W = 1.4 KG
Temperature and Humidity	Operating Temperature	0°C ~ 45°C
	Storage Temperature	-40°C ~ 80°C
	Working Humidity	10% ~ 95% @40°C (No condensation)
Operating System	Support	Windows 10/11, Linux
