AMD Ryzen™ AI 9 365
10 Cores & 20 Threads
GPU & NPU
AMD Radeon™ 880M Graphics
I/O Interfaces
Support Quad Display via, 1x HDMI 2.1 ,1x DP 2.0, 2x USB4.0, 3x USB 3.2, 2x USB4, 1x Type-C, 1x 3.5mm Combo Audio Jack
Memory
Dual SoDIMM DDR5 Slots, Supports up to 64GB / Max 96GB, High-speed next-gen multitasking system configuration
SMART 9170 PRO 365 AI PC
Multi-OS Compatibility
Window11/Linux
Storage
2x M.2 Key M 2280 PCIe 4.0 Gen4 NVMe SSD Support
High-Speed LAN & Wifi + BT Connectivity
Dual Gigabit LAN Ports, 2x RJ45 Ports, 10/100/1000Mbps / 2.5Gbps via 2x LAN IC RTL8125, M.2 Key E 2230 Module slot, Wireless Wi-Fi / BT module connectivity
Key Features
- Unmatched Portability
- High-Speed Peripheral Support
- Ultralight, VESA-Ready Design
- Future-Ready OS Compatibility
- Optimized Energy Efficiency
| Category | Type | Description |
|---|---|---|
| Technical Specification | CPU | AMD Ryzen AI 9 365 |
| Multi Displays | Support quad display | |
| Interface |
1 x HDMI2.1 1 x DP2.0 2 x USB4.0 |
|
| Memory | Dual SoDIMM DDR5 Max. 96 GB | |
| Storage | 2* M.2 Key M 2280 PCIE4.0 GEN4 SSD | |
| OS | Window11/Linux | |
| WatchDog | Support | |
| Auto Power On | Yes | |
| Power Input | 19V DC IN, 120W | |
| Dimension | 140mm(L) x 139mm(W) x 38mm(H) | |
| Operating Temp. | -5~45°C | |
| Operating Humidity | 10%~90% non-condensing | |
| Storage Temp. | -20~70°C | |
| Storage Humidity | 5%~95% non-condensing | |
| Lan IC | 2 x LAN IC RTL8125 | |
| Lan Interface | 10/100/1000Mbps/2.5Gbps | |
| Lan Connector | 2 x RJ45 Ports | |
| Wireless Type | M.2 Key E 2230 Module | |
| Wireless Interface | WiFi/BT Module | |
| USB |
3 x USB3.2 (10Gb) 2 x USB4 (PD-in 100W, PD-out 15W, DP out) |
|
| Button | 1 x Power Button, 1 x Reset Button | |
| Audio | 1 x 3.5mm Combo Audio Jack | |
| Power | 1 x Type-C |
