AMD Ryzen™ 7 260
8 Cores & 16 Threads, Max Boost Clock 5.1GHz
GPU & NPU
AMD Radeon™ Graphics 780M
I/O Interfaces
1x DP 2.1, 1x HDMI 2.0, 1x USB4, 2x USB 3.2, 1x USB-C, 1x USB4 full-functioned Type-C, 1x CTIA 2-in-1 Audio Jack
Memory
Dual Channel SO-DIMM DDR5 Slot, Supports up to 64GB, High-speed next-gen system memory configuration
SMART 9170 ELITE 260 AI PC
Multi-OS Compatibility
Window11/Linux
Storage
2x M.2 Key M for NVMe 2280 SSD
High-Speed LAN & Wifi + BT Connectivity
Dual Gigabit Network Ports via Realtek RTL8125 Controller, Onboard 2x RJ45, 1x M.2 Key E for 2230 Wi-Fi & Bluetooth Module expansion connectivity
Key Features
- Unmatched Portability
- High-Speed Peripheral Support
- Ultralight, VESA-Ready Design
- Future-Ready OS Compatibility
- Optimized Energy Efficiency
| Category | Type | Description |
|---|---|---|
| Technical Specification | CPU | AMD Ryzen™ 7 260 |
| Max. Boost Clock | 5.1GHz | |
| GPU | AMD Radeon™ Graphics 780M | |
| Type | Dual Channel SO-DIMM DDR5 Up to 64 GB | |
| Interface |
1 x DP2.1 1 x HDMI2.0 1 x USB4 |
|
| Controller | 2 x Realtek RTL8125 | |
| LAN Interface | 2 x RJ45 (10/100/1000/2500Mbps) | |
| Audio Codec | Realtek HD ALC897 | |
| Audio Interface | 1 x CTIA 2in1 Audio Jack, supports Line-out + Mic-in | |
| M.2_N1/N2 | 2 x M.2 Key M for NVMe 2280 SSD | |
| WiFi & Bluetooth | 1 x M.2 Key E for 2230 Wi-Fi & Bluetooth Module | |
| USB3.2 | 2 x USB3.2 | |
| USB2.0 | 1 x USB2.0 | |
| USB-C |
2 x USB-C Front USB-C: 1 x USB 3.2 10Gb Rear USB-C: 1 x USB4 full-functioned |
|
| Size | 127 mm x 129 mm x 55 mm (L x W x H) | |
| Standard Port | 19V / 20V DC-in | |
| Operating Temp. | 0°C to 50°C | |
| Storage Temp. | -20°C to 70°C | |
| Cooling | Active Cooling |
