Processor
Intel Celeron N5095 2.0GHz up to 2.9GHz
GPU
Intel UHD Graphics
Dual Display ( VGA + HDMI )
Dual Display ( VGA + HDMI )
I/O Interfaces
1x VGA 1x HDMI 1.4 (4k@30Hz)
2x USB 3.0, 2x USB 2.0
2x RS232 COM ports
1x Audio Jack
2x USB 3.0, 2x USB 2.0
2x RS232 COM ports
1x Audio Jack
Memory
SO-DIMM DDR4 slot 3200MHz Max 32GB
Mini PC SMART 9530 N5095
Multi-OS Compatibility
Windows 10 (or higher) and Linux
Storage
Dual storage M.2 2280 NVME SSD and 2.5″ SSD
High-Speed LAN & Wifi + BT Connectivity
2x RJ45 Giga LAN
Wi-Fi 5/ 6 + Bluetooth 5.0 combo
Wi-Fi 5/ 6 + Bluetooth 5.0 combo
Key Features
- Compact Professional Thin Client,
- Fanless Edge Computing Node,
- Silent POS Terminal | 24/7 Digital Signage Hub,
- Dual-Network Firewall Appliance,
- Legacy Hardware Controller
| Category | Type | Description |
|---|---|---|
| Basic Information | CPU | Intel Celeron N5095 |
| TDP | 10W | |
| Motherboard | 120x120 mm Customize Size | |
| BIOS | AMI EFI BIOS | |
| Chipset | Intel Kaby Lake | |
| Memory |
1x SO-DIMM DDR4 Slot Support 4GB / 8GB / 16GB DDR4-2133/2400, LPDDR3-1866, DDR3L-1600 |
|
| OS Support | Windows 10, Windows 11, WES10, WES11, Linux | |
| PXE | YES | |
| Audio | Realtek ALC897 2-channel Sound Chip | |
| Network | Onboard Realtek 8111H/8106E PCI-E Gigabit Ethernet NIC 10/100Mbps/1000Mbps BaseT LAN | |
| Video | Intel® UHD Graphics | |
| Input / Output Port | Switch | 1x Power On/Off Switch |
| Power | 1x 12V DC In | |
| LED | 2x LED | |
| USB | 2x USB 2.0, 2x USB 3.0 | |
| Display | 1x VGA, 1x HDMI(1.4) | |
| LAN | 2x RJ45 Giga LAN | |
| Audio | 1x MIC & 1x SPK | |
| RS232 | 2x 9 Pin RS232 Ports | |
| Other | 2x Kensington Lock Holes | |
| Wi-Fi | Module | 1x Mini PCIE-half Port for Wi-Fi Module |
| Antenna | 2x Inner RF Cables and 2x External Antennas | |
| Storage | SATA | 1x SATA3.0 Slot for SATA HDD or SSD |
| NVME | 1x M.2 2280 SATA/PCIE/NVMe SSD, up to 2TB | |
| Production Dimension & Details | Size | 173x127x39mm |
| Weight | Net 0.8kg, Gross 1.2kg | |
| Shell | Black Color Aluminium Alloy | |
| Cooling Mode | Fanless | |
| Functions | Calls On Function Automatically, Wake-On-LAN, Kensington Lock | |
| Power & Working Environment | Input | 100-240V AC / 50-60Hz |
| Output | DC+12V~19V, Recommend 12V/5A | |
| Operating Temperature | 0°C / +70°C Centigrade | |
| Storage Temperature | -20°C / +85°C Centigrade | |
| Relative Humidity | 0%~90% @30°C (Non-Condensing) | |
| Package Content | Standard |
1x Mini PC, 1x Power Adapter, 1x Power Cord, 1x Screws Bag, 1x HDMI Cable, Wi-Fi Antennas (Optional) |
